The Bit Buffer is a tiny (2” x 1.5”) buffer that uses an ultra-low distortion, low-noise Burr-Brown op amp. Place it at the beginning of your pedal chain to prevent high-frequency loss (tone suck), or right before a long cable to a pedalboard or amp.
The Bit Buffer is always on when power is connected. An internal LED is visible below the power jack.
Size:2" x 1.5" x 1.2"Input impedance:1 MΩ
Output impedance:< 1 kΩ
Frequency response (± 3 dB):20 Hz - 40 kHz
Signal-to-noise ratio:90 dB
Power:9-18 VDC, center negative
Current:20 mA
